HPSE-6
Product Introduction
Specifications
Sample Throughput
Sample Vessel Sizes
Collection Vessel Sizes
Pressure Range
Real-Time Pressure Display
Temperature Range
Real-Time Temperature Display
Operating System
Dimensions (WxDxH)
Weight
2 - 6
1 - 40 mL
50 - 250 mL
ambient - 20 MPa
Yes
ambient - 200°C
Yes
Onboard Windows PC
719 x 509 x 716 mm
91 kg
Summary:
The HPSE-6 is an automated high-pressure solvent extraction instrument designed to process 2-6 samples in parallel. High-pressure solvent extraction (HPSE) is the process by which solvent is introduced to solid, semi-solid, or viscous matrices under high pressure and temperature to extract semi-volatile targets from samples that would otherwise be impossible to process by solid phase extraction. HPSE extraction methods can be applied to both the food and environmental industries for preparing samples for quantification by either LC or GC-MS. The collection vials containing extract are compatible with LabTech CDS Analytical nitrogen concentrators and vacuum concentrators. More information on those supporting product lines can be found at the bottom of this webpage for related products.
Product Features
Sealed Collection Vessels
Sealed collection vessels eliminates the possibility of losing sample from splashing or causing cross-contamination.
Real-Time Monitoring
Pressure and temperature are monitored and logged in real-time to always ensure safe operation and diagnosis any problems as quickly as possible.
Anti-Clogging Design
The anti-clogging design implements a large diameter tubing system to address the painful points of clogging from large particulates.
Applications
Category | Description (Hyperlink in Blue Color) | Part Number |
|---|---|---|
Consumable | Filter Tip Assembly for Small Volume Sample Needles for the SPE2000-6 or -8 (10 tips / bag) | LT001-15012 |
Instrument | SPE2000 8-Channel Automated Solid Phase Extraction Instrument for Food Applications | LT004-15001 |
Instrument | SPE2000 8-Channel Automated Solid Phase Extraction Instrument for Environmental Applications | LT002-15001 |
Instrument | SPE2000 6-Channel Automated Solid Phase Extraction Instrument for Environmental Applications | LT001-15001 |
Instrument | SPE2000 6-Channel Automated Solid Phase Extraction Instrument for Food Applications | LT003-15001 |
Parts | 16-Position Large-Volume Sample Rack Assembly, for 1L Bottles | LT001-15005 |
Parts | 36 Position Sample Rack for 50mL Centrifuge Tubes and 40-1mL Concentration Cups for SPE2000-6 | LT001-15002 |
Parts | Six Channel Sample Loading and Filtration Assembly for the SPE2000-6 | LT001-15011 |
Parts | 1L Reagent Bottle, 1pc/bag (SPE2000-6 or -8) | LT001-15010 |
